Product Details:
Place of Origin: CHINA
Brand Name: AIR
Model Number: Dust filter cartridge
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Inner poly bag,Outer cartons
Delivery Time: around 2 weeks upon receipt signed&stamped PO
Payment Terms: T/T(Negotiation)
Supply Ability: around 30000pcs per year

5um,0.5um,2um,0.2um,Long Pulse Pleated Dust Filter Cartridge , Wide folds Industrial

Description
OD: 165mm ID: 147mm
Inner Core: Galvanized Steel Height: 2000mm
Filter Material: Polyester+waterproof And Anti-oil Efficiency: 99% (Particles ≥5μm)
Name: Long Pulse Pleated Dust Filter Cartridge
High Light:

dust collector filter cartridge

,

dust extractor filter cartridges

Dust Collector Industrial Smoke Filter Cartridges 2000mm long filter cartridge​ ​Description:

Optional Filter Materials:

1.Standard white polyester

2.Oil and water repellent polyester

3.Anti-static polyester (Macromolecule antistatic & aluminized anti-static)

4.PTFE coating polyester (glue coating & high temperature heat coating)

5.Flame retardant polyester

6.Double Anti-treated polyester(Antistatic + flame retardant;Oil and water repellent + antistatic;PTFE coating + anti-static)

7.Cellulose / polyester blended

8.Cellulose / polyester blended with fame retardant

9.Imported Donaldson Tetratax polyester

Specification:

Model O.D Length Filtration surface(m2)
162*2000 Φ178mm 2000mm 5m2
162*1000 Φ352mm 1000mm 2.5m2

We offer Surface Coatings and Chemical Impregnations to improve dust cake release, as well as provide a Hydrophobic and Oleo phobic finishes. Available in Polyester, Cotton, Polypropylene, Polyamide & Aramid staple, multifilament and monofilament yarns as finished bags. Suitable for wet applications such as Sugar, Pharmaceutical, Waste Water, Beverage Industry, Effluent Treatment.
In most cases Long Pulse Cartridge Filter are custom made in various sizes and constructions to fit your specific requirements, along with high temperature capabilities, fire retardant, PTFE membrane, conductive and high efficiency type materials. Standard Filter provides various pleat spacing and pleat depths.
A brief list of materials available along with top and bottom constructions are listed below.
Samples of the 100% Cellulose, 80% / 20% Cellulose / Polyester and Spun Bond Polyester materials are attached on the back page.

Applicable to dusting spray, sand blasting, pigment industry, wood processing.

Dust filter cartridge

1) Imported long fiber polyester filter media,fiber interwoven,evenly distributed.

2) Good abrasion resistance,and the capability of withstand airflow pulse inverse blow is better than traditional filter media.

3) Smooth filter media surface,not sticky.

4) Excellent chemical resistance.

5) Electro-galvanized / stainless steel cover, central skeleton.

6) Professional sealing obturator elastic neoprene.

7) Good filter material stiffness,can be repeated washed.

8) Operating temperature ≤ 135 ° C.

9) Greatly increase the effective filtration area.

10) Ensure a low steady differential pressure, improve the circulation of air flow.

11) Small filter cartridge element, easy to install.

12) Especially suitable for large dust concentration industry.

Dust filter cartridge

Structural Features For Dust Filter:

1.End caps with fingerprint-resistant steel or galvanized steel

2.Galvanized central skeleton

3.High quality foam rubber gaskets

4.Wide folds,easier for cleaning



Optional Structures:

1.Stainless steel end caps

2.Stainless steel center core

3.Custom pleat number to meet different requirements according to actual conditions

4.Lengths and diameters to meet different requirements according to actual conditions

5.Silicone rubber gaskets

6.Anti-static grounding wire

7.Special treatment,for filter media,such as anti-static, PTFE coating,etc.



   https://youtu.be/IV795B_37vU

   https://www.youtube.com/watch?v=h7xUgYrQosA

Dust Collector Industrial Smoke Filter Cartridges PU Top Filter 2000mm long filter cartridge​ show:

5um,0.5um,2um,0.2um,Long Pulse Pleated Dust Filter Cartridge , Wide folds Industrial 0

5um,0.5um,2um,0.2um,Long Pulse Pleated Dust Filter Cartridge , Wide folds Industrial 15um,0.5um,2um,0.2um,Long Pulse Pleated Dust Filter Cartridge , Wide folds Industrial 2
