Product Details:
Place of Origin: CHINA
Brand Name: Air
Model Number: AR-PE1492Dust filter cartridge
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Inner poly bag,Outer cartons
Delivery Time: around 2 weeks upon receipt signed&stamped PO
Payment Terms: T/T(Negotiation)
Supply Ability: around 30000pcs per year

5um,0.5um,2um,0.2um Low Pressure Drop Dust Filter Cartridge , Galvanized Mesh Industrial Cartridge Filters

Description
Application: WAM Concrete Plant Silo Filter Cartridge Shape: Filter Elements /cylinder Cartridge
Top/Bottom: Galvanized Mesh Top Media: PU
Inner&Outer Core: Galvanized Mesh Height: 920mm
Filter Media: Polyester+waterproof And Anti-oil Replacing: WAM Filter Cartridge
Name: Low Pressure Drop Dust Filter Cartridge
High Light:

dust extractor filter cartridges

,

pleated filter cartridge

Low Pressure Drop Pleated Filter Cartridge , Industrial Hepa Filter Careful Construction Description​:

Dust filter cartridge

Detailed informations(Products):
1. Pleated air filter cartridges are widely used in dust collectors in various operating environments, from shot blasting to wood dust filtration. Thanks to plenty of filter media selection and many finishing treatment techniques, we can always provide you a proper filter element to clean your air perfectly.
2. Features: Problem-free installation, careful construction, low pressure drop and competitive price.



Model Filter area(m2) Length(M) Temperature(℃) Media Weight(g/m2) Air permeability Media type
P1 2.3 1 135 270 7m3/m2/min@12mm WC Spun bond polyester
P2 4.6 2 135 270 7m3/m2/min@12mm WC Spun bond polyester
D1 2.3 1 135 270 7m3/m2/min@12mm WC Antistatic spun bond polyester
D2 4.6 2 135 270 7m3/m2/min@12mm WC Antistatic spun bond polyester
F1 2.3 1 135 270 7m3/m2/min@12mm WC Spun bond polyester+PTFE
F2 4.6 2 135 270 7m3/m2/min@12mm WC Spun bond polyester+PTFE


Structure:


Item Material(Standard) Material(Alternative)
Filter Media Cellulose/Synthetic fiber/ All kinds of H&V air filtration`s filter
Nanofiber/Polyester fiber media selection
Top cap/ Galvanized steel Stainless steel,Color-coated steel,
Bottom cap recyclable plastic ABS
(Open/Closed)
Gasket EPDM Urethane/Silicone
Inner Mesh Galvanized steel Stainless Steel,Color-coated steel,
Recyclable PP
Outer Straps/Outer Optional Galvanized steel,Stainless Steel,
Mesh Glued or ultasonic straps
Finishing Treatment Teflon-coating,waterproofing,oilproofing,flame-retarding
treatment, antistatic coating,etc


Company advantages:
1. The biggest manufacturer of filters in China;
2. H&V`s biggest customer in China;
3. Our vast experiences and the state-of-the-art laboratory enable us to provide customization;
4. Welcome you to our factory and you will be convinced by our advanced workmanship and big scale.

Applications:
Industrial air filtraton of dut and fumes in many industries: Metallurgy, Cement, Woodworking, Chemicals Powder coating, Plasma/laser cutting, Sandblasting, Textiles, Welding and Casting, Food&Beverage, Aerospace.

We warmly welcome:
-- Famous brand to do OEM;
-- End users or agents to find replacements here;
-- Dust collector manufacturers to do customization.

https://www.youtube.com/watch?v=aUaBDyIUt10

https://youtu.be/IV795B_37vU

Low Pressure Drop Pleated Filter Cartridge , Industrial Hepa Filter Careful Construction​ Show:
